(1) Technical Principle
Crafted based on advanced membrane separation + PSA coupling technology, membrane separation is an advanced gas separation technology that achieves separation by leveraging the difference in permeation rates of gas components through polymer membranes. It is used for the separation and purification of gases such as nitrogen, helium, and hydrogen, featuring high purification concentration and low loss. Meanwhile, PSA technology is characterized by high purification throughput and operational convenience. The combination of these two technologies delivers advantages including large throughput, high purity, and minimal loss.
(2) Product Features
Purification efficiency ≥90%.
High purification purity: Meets the demand for purifying ≥50% raw helium (hydrogen), stably supplying ≥99.0% helium to fulfill requirements across various fields.
High level of intelligence: Excellent human-machine interface, with real-time monitoring and operation via cloud technology.
(3) Application fields
Lithium battery manufacturing, production leak detection, scientific research tail helium recovery, hydrogen recovery, etc.
(4) Parameters
Rated throughput | Capacity | 30 L/min |
Feed gas helium content | Input Purity | ≥5.0%He |
Purified helium purity | Output Purity | ≥99.0%He |
Purification efficiency | Recovery | ≥90.0% |
Dimensions (mm) | Dimension | 900*800*1700mm |
